Ferry Push Car
Production: 30000-300000 m³/year
Raw materials: Cement, lime, sand( or fly ash), gypsum, aluminum powder, water.
Application: Ferry push car is mainly used in the aerated concrete equipment to ferry the mould box to pre-raising static place after casting.
MOQ :
1
Introduction of ferry push car
Ferry push car is a necessity for various steam-cured products manufacturers to connect pressing section with steam curing section for reversing drag. This product is designed on the basis of imported products, it features by powerful drag and push.
The car can do accurate stopping, location and track connection after fast transverse movement; also it can do frequency conversion slow speed movement when carrying load and frequency conversion fast speed movement when returning. The car is equipped with longitudinal power set which can drag and push 20 steam curing dollies loaded with 3t products.
Features of ferry push car
1. Structure is simple and practical, easy to install and repair
2. Drive power is small
3. Good operational reliability
4. Easy operation and maintenance
5. Long working life.
Working principle of ferry push car
Pouring Ferry Cart: It is composed of two parts: a frame and a driver.
Frame: its beam frame is rectangular steel structure welded by rectangular steel tube and steel angle with anti-skidding riffled plate and guide rail for autoclave cart or mould on it, whose stiffness can afford the local maximum load.
The driver is divided into active and passive drive. Active drive consists of the motor, reducer, drive shaft, coupler, and wheel etc. controlled by the electric box. When electric box begins to transmit electricity to the motor, active driving system drives the ferry cart, conveying cutting-finished blocks to autoclave line or transporting after-autoclaving finished products to pile site.
This machine has double functions: ferrying the kiln cart and pushing it into the kiln. It can run stably and reliably, save large labor and improve production scheduling speed.
Previous:
Turn Over HoistNext:
Mould, Mould Base PlateIf you need more details about our products, please write what you need, we will contact you asap with favorable prices!
Feed opening: 820x700-1600x2080mm Feeding size: ≤500mm Application: All kinds of ore crushing, railways, highways, energy, cement, chemicals, construction and other industries. Processible Materials: Side length from 100 to 500 mm below the material, the compressive strength of up to 350 MPa. Limestone, coal gangue, river pebbles, granite, iron ore1
Feed opening: 150×250-300×1300mm Feeding size: 125-250mm Production: 1-2200 t/h Application: Metallurgy industry, mine industry, chemical industry, cement industry, construction industry, refractory materials industry etc. Processible Materials: limestone, pebble, calcite, granite, quartz, concrete, dolomite, basalt, iron ore, limestone, constructi1
Cone diameter: 600-2200mm Feeding size: 35-300mm Production: 12-1000t/h Application: Metallurgy, building materials, road construction, chemical and silicate industry. Processible Materials: Barite, marble, calcite, kaoline, coal, gypsum, concrete, river pebbles, granite, basalt, iron ore, limestone, quartz stone, diabase, iron ore, gold mine, copp1
Feeding size:≤25mm Production: 0.5-500t/h Application: Widely used in dry and wet grinding for all kinds of ores, it also can be used for the manufacture industries, such as cement, silicate, new building material, refractory material, fertilizer, ferrous metal, nonferrous metal and glass ceramics. Processible Materials: Cement, silicate, fertilize1
Production: 180-1000(t/d) Specification: Φ2.5×40m-Φ6.0×95(m) Application: Lean iron ore magnetizing roasting, cement making industry, chromium and nickel-iron oxidizing roasting in steel plants of metallurgy Processible Materials: Dolomite, active lime, cement clinker, and bauxite.
Production: 30000-300000 m³/year We are the leading manufacturer of AAC air turn over cutting machine in China with 15 years' producing experience, we can provide all the types equipments for AAC block production line.
