Slurry Pump
Production: 5-600 m³/h
Application: It is used for pumping heavy slurry in agriculture, petrochem, manufacturing, energy, and mining.
Applicable materials: Concrete, Fly ash, sand, lime, gypsum, cement
MOQ :
1
Introduction of slurry pump
The purpose of using the slurry pump is to mix autoclave aerated concrete slurry into pouring slurry after watering.
The driving power of mixing is from Cycloidal pin wheel reducer which goes anti-clockwise. And blender runs following it to mix slurry and water completely. Then pouring slurry is done.
Features of slurry pump
1. High strength cast iron pump construction with reinforced ribs for excellent high-pressure strength and safety.
2. Impeller features pump out vanes as standard to prevent recirculation and to extend seal life.
3. Heavy duty angular contact bearings in wet end and single or double row deep groove roller bearings in drive end.
4. Regreasable or oil lubricated bearings.
5. Packed gland with product lubrication as standard. External gland flushing or mechanical seal options available.
6. Vertical Slurry Pump range is of a vertical cantilevered design that features hard alloy wear parts or full elastomeric protection on all submerged components. This allows this pump to be used in highly corrosive applications.
Working principle of slurry pump
Slurry in the production of aerated concrete delivery system good for fly ash slurry or mortar. Pulp and waste slurry pool in the pool with vertical pump, horizontal in the storage pool pulp slurry.
Vertical submerged pump for the semi-open impeller, the impeller side stretches with high-intensity mixing blades, work back mixing, fly ash slurry or mortar can be impurities in the particles completely crushed, and crushed the front cover can be installed impurities of the props, to prevent clogging.
The purpose of using slurry pump is to mix autoclave aerated concrete slurry into pouring slurry after watering.
The driving power of mixing is from cycloidal pin wheel reducer which goes anti-clockwise. And blender runs following it to mix slurry and water completely. Then pouring slurry is done.
Technical data
Equivalent
Type
Material
quality
Clear water
performance
Q
H
n
η
(NPSH)r
Protect
Impeller
Capacity
Head
Speed
Effciency
4/3C-AH
TD75-100C
M
M
86.4-198
9-52
1000-2200
71
4-6
4/3D-AH
TD75-100D
4/3C-AH
TD75-100C
RU
RU
79.2-180
5-34.5
800-1800
59
3-5
4/3D-AH
TD75-100D
4/3C-AH
TD75-100C
M
M
79.2-180
97.2-194.4
9-53
1000-2200
55
4/3D-AH
TD75-100D
4/3E-HH
TD75-100E
M
M
126-252
12-97
600-1400
50
2-5
4/3C-AH
TD75-100C
type for reference
(m)
cover
(m³/h)
(m)
(r/min)
(%)
