Coal Mill
Production: 8-43t/h
Feeding size: <25 mm
Application: Mainly used for grinding coal of various hardness and the raw ore pulverizing system in cement, metallurgy and chemical industry.
Processible Materials: Raw coal, etc
MOQ :
1
Introduction of coal mill
Coal mill is the important auxiliary equipment for a coal-powder furnace, it has three methods to crush the coal lump and grind them into powder, they are: crushing, impacting and grinding.
It is often used for grinding coal with various forms of hardness and the raw ore pulverizing system in cement, metallurgy and chemical industry.
Air swept coal mill is the main equipment in cement plant for both drying and grinding of the powders. Compared with the ordinary ball mill, it has advantages of higher capacity, more convenient operation, safer usage, and more reliable performance.
Coal mill is used to grind, pulverize and dry coal before the coal is transmitted the boiler. The coal is feed into the coal mill via an inlet pipe so that the roller coal mill such as ball mill or vertical mill can pulverize the coal into particles.
Features of coal mill
1. Reliable performance. The edge transmission. The motor drives the mill through the reducer and the big and small gears.
2. Safer usage. The air swept structure with drying chamber leads to the greater adaptability to the water content of raw coal.
3. Higher yield. The grinding chamber adopts the combined arrangement of stepped lining board, double stepped lining board and corrugated lining board to improve its processing ability.
4. Convenient operation. The feeding device adopts oblique wind louver structure, which enhances the heat exchange capacity and effectively prevents the blocking phenomenon.
Working principle of coal mill
The raw material is fed into mill by feeding equipment. The hot wind enters into the mill by inlet end. As the mill cylinder rotates, the coal and hot air exchange heat in the mill.
The coal is crushed and ground in the mill. When the coal is ground, the powder is brought out of the mill by the hot air going through the mill.
Technical data
Spec.
Φ2.2
Φ2.4
Φ2.4
Φ2.5
Φ2.6
Φ2.8
Φ2.9
Φ3.0
Φ3.2
Φ3.4
Φ3.8
Φ3.8
Speed
22.4
20.4
20.4
20
19.7
18.3
18.8
17.3
16.9
17.5
16.4
16.4
Capacity
8~9
12~14
11~12
10
13~14
16~17
14~16
19~20
27~29
28~30
38~40
41~43
Fineness
10-12
8-10
8-10
8-10
8-10
8-10
8-10
8-10
8-10
12
12
12
Feeding
<25
<25
<25
<25
<25
<25
<25
<25
<25
<25
<25
<25
Grinding Media
20
22
22.5
22
28
32
35
43
50
55
80
85
Moisture
Inlet
<10
<10
<10
<10
<10
<12
<10
<10
<10
<12
<12
<12
Outlet
<2
<2
<2
<2
<2
<2
<2
<2
<2
<2
<2
<2
Temp.
Inlet
<350
<350
<350
<350
<350
<350
<350
<350
<350
<350
<350
<350
Outlet
60~80
60~80
60~80
70~90
70~90
60~80
60~80
70~90
80~90
60~80
60~80
60~80
Main
ZD60
ZD60
ZD60
ZD60 MBY450
ZD70
ZD70 MBY500
ZD80 MBY560
ZD80 MBY560
JDX630
JDX710
MBY710
MBY800
Main
250
280
315
315
400
500
500
630
710
800
1250
1400
Weight (t)
46
54
76
62
98
107
78
124
148
162
178
220
(m)
×4.4
×4.75
×4.5+2
×3.9
×5.25+2.25
×5+3
×4.1
×6+3
×6.75+2
×6+3
×7+2.5
×7.25+3.5
(r/min)
(t/h)
R80 (%)
Size(mm)
Loading(t)
(%)
(℃)
Reducer
MBY450
Motor(kw)
